Bionet Cardio P1 – Interpretive 12 Channel PC Based ECG / EKG System

The system performs simultaneous 12-lead ECG acquisition and stores up to 200 ECG and pulmonary function tests. Its full disclosure ECG function displays the most recent 5-minute full-channel ECG, helping identify missed abnormal waveforms. Long-term ECG recording, automatic arrhythmia detection, and HRV analysis support accurate clinical evaluation.

Integrated spirometry testing includes FVC, SVC, and MVV with pre- and post-bronchodilator comparison. The Cardio7-S produces clear full-size A4 ECG and PFT reports and connects seamlessly to EMR and PACS systems through BMS-Plus software via LAN or Wi-Fi.

Features

Automated ECG Workflow

Streamline the entire ECG process with one-touch automation that moves seamlessly from recording to interpretation, reporting, and data sharing.

High-Capacity Internal Memory

Store and access large volumes of patient ECG records directly on the device for fast retrieval and efficient data management.

Instant On-Screen Review

Review ECG results immediately on screen before printing to ensure accuracy and save time and paper.

Extended Real-Time Monitoring

Capture continuous ECG data while automatically detecting arrhythmias in real time for deeper clinical insight.

Rapid Pre-Acquisition Mode

Generate ECG reports almost instantly with quick capture and documentation features designed for busy clinical environments.

Advanced Professional Reporting

Choose from multiple diagnostic report styles to support detailed analysis and flexible presentation for clinical decision-making.

Specifications

ECG CAPABILITIES
ECG Leads	Simultaneous 12-channel ECG and acquisition
Recording Channels	3CH+3RHY, 3CH+1RHY, 6CH+1RHY, 12CH, 6CH+ST map, 1CH long time (1 min, 3 min, 5 min, 10 min, 20 min, 30 min), special beat report (Text, Guide, Vector, ST map)
Gain	2.5, 5, 10, 20, Auto (I–aVF: 10, V1–V6: 5) mm/mV
Printing Speed	5, 12.5, 25, 50, 100 mm/sec
SAMPLING & FILTERS
Sampling Rate	Analysis sampling rate: 500 Hz, digital sampling rate: 8,000 Hz
Filters	AC (50/60 Hz, -20 dB or better), muscle (25–35 Hz, -3 dB or better), baseline drift (0.05 Hz, 0.1 Hz, 0.2 Hz, -3 dB or better), low pass filter (off, 40 Hz, 100 Hz, 150 Hz)
PATIENT DATA
Patient Data Fields	ID, name, birthday, age, gender, height, weight, race, smoke, department, room no., study description, accession no., referring physician
MEASUREMENTS
Basic Measurement	Heart rate (30–300 bpm, ±3 bpm), PR/RR interval, QRS duration, QT/QTc interval, P-R-T axis, SV1/RV5/R+S amplitude
ELECTRICAL & PROTECTION
Internal Noise	20 uV (p-p) max
Input Impedance	≥ 50 MΩ
Input Voltage Range	±5 mV
CMRR	> 105 dB
DC Offset Voltage	≥ ±400 mV
Frequency Response	0.05–200 (within -3 dB)
Protection	Isolated, defibrillation and ESU protected
SIGNAL QUALITY CONTROL
Detection Features	Pacemaker pulse detection, lead fault detection, signal saturation detection
POWER & CONNECTIVITY
Input Power	5VDC (USB), max. 0.5A
Communication	USB data communication (to PC)
SAFETY
Safety Conformity	Class I, Type CF applied parts (ECG electrodes)
ENVIRONMENTAL
Operation	Ambient temperature: 10 to 40ºC, relative humidity: 30 to 85%, atmospheric pressure: 700 to 1060 hPa
Storage/Ship	Ambient temperature: -20 to 60℃, relative humidity: 10 to 95%, atmospheric pressure: 500 to 1060 hPa
PHYSICAL
Dimensions	Body: 90.75(W) × 103.5(D) × 24.93(H) mm
Weight	Approx. 110 g

What's Included

• Cardio P1 Main Unit
• 10 Lead ECG Patient Cable
• Alligator Clips
• Electrodes
• Power (USB) Cable
• IV Pole Hanger
• Silicon Pad
• Operation Manual
• Diagnostics Guidebook
• Quick Reference Guide
• 3-Year Warranty Card
• USB Lock-Key with Cardiosync Software Included
