Dreampod Vmax Float Pod

Premium Space Inside

The Dreampod Vmax Float Pod is a roomy flagship for couples, larger guests, or anyone who wants extra space. Size: 2624 mm L × 1771 mm W × 1319 mm H (8.60 × 5.81 × 4.32 ft). Inner length 2404 mm (7.88 ft) for full-body comfort.

Glossy fiberglass with a foam core improves soundproofing and heat retention and wipes clean. A gas-spring door opens smoothly. Inside: passive airflow and an anti-slip floor. A magnetic-drive pump, 2000W+ titanium inline heater, 10-micron filter, UV sanitation, and dual chemical dosing keep water clear. LED lighting and underwater speakers elevate each float.

Manage everything from a web control panel: session time, temperature, music, UV, and dosing. Auto Mode holds your set temperature and built-in reports simplify operations. Vmax delivers quiet, clean, consistent floats that attract clients and boost revenue.

Features

• Web-based control panel for daily operation
• UV light integrated into the filtration system
• Dual chemical dosing for precise water care
• High-efficiency inline titanium heater
• Built-in underwater speakers with clear audio
• 10-micron filtration for fine debris
• Soothing interior LED lighting
• Anti-slip floor surface
• Auto Mode maintains your preset temperature

Specifications

VMAX FLOAt POD

Overall Length: 2624 mm (8.60 ft) Inner Length: 2404 mm (7.88 ft) Overall Width: 1771 mm (5.81 ft) Overall Height: 1319 mm (4.32 ft) Power Requirements Single-phase outlet on its own dedicated GFCI breaker, 15 A North America: 220 V / 60 Hz, 15 A (new models are 110 V) Australia/New Zealand: 240 V / 50 Hz, 15 A Asia/Europe: 220 V / 50 Hz, 15 A East Japan: 200 V / 50 Hz, 15 A West Japan: 200 V / 60 Hz, 15 A

Room Design & Setup Recommendations

Environment

• Wet, salty space (~450 kg / 1000 lb Epsom salt). Use non-porous finishes; control light and sound.

Move-In & Space

• Breaks into 3 parts: base, lid, back panel.
• Base: 2624 mm (8 ft 6 in) L × 601 mm (2 ft) H × 1771 mm (5 ft 8 in) W.
• Hallways for 90° turns: ≥ 1400 mm (4.5 ft); fits standard doors.
• Room minimum: 4000 × 3000 mm (14 × 10 ft); ceiling ≥ 2200 mm (7 ft).
• Clearances: ≥ 800 mm (2 ft) behind pod for connections. Engine box sits next to pod.

Power & Network

• Single-phase outlet on its own GFCI breaker.
• Hard-wired CAT5 to the main router (no powerline/wireless bridges). Internet required for setup; control works on devices on the same network.

Surfaces

• Floors: seamless non-slip vinyl/rubber; if tile, waterproof subfloor + epoxy grout.
• Walls: epoxy paint, coved base, FRP panels in splash zones.

Air & Temperature

• Mechanical ventilation (HVAC + bath fan).
• Target 78–82°F (26–28°C); local room control preferred.

Lighting

• Soft, dim for sessions; bright mode for cleaning.

Water & Drainage

• Shower in-room for pre/post rinses.
• Floor drain between shower and pod (or open shower using its drain).
• Dedicated water hookup; fill/top up via garden hose.
• Pod is closed-loop; drain with a submersible pump when needed.

Safety & Flow

• Post instructions; require a liability waiver (feet toward back wall).
• Keep grooming items in a separate post-float area to speed changeovers.
